用于变压器、电机、电器等绝缘

 任意宽度均可裁切，一旦裁切不可退货

ntertape polymer group

POLYESTER FILM / POLYESTER NON-WOVEN ELECTRICAL TAPE

Description

The combination of Polyester Film and Polyester Non-Woven Materials can be used in a wide variety of electrical applications.  Acrylic adhesive system combination of tear and puncture resistance, high tensile strength with elongation, and excellent dielectric strength.

PRODUCT APPLICATIONS

Ideal for high volume coil wrapping applications, ground and barrier insulation, outer protective wrap for bobbin applications, coil end insulation anchoring leads and terminal boards.

NOMINAL VALUES

The following data are nominal values based on PSTC, ASTM and other standard test.  The data should not be considered as specifications.

Backing Thickness: 3.5mil (0.089mm)

Adhesive: Acrylic
Color: white
Total Thickness: 4.5mil (0.114mm)

Dielectric Strength 2 : 5000 Volts

Temp. Class 2 :155 C / F

Insulation Resistance 2 :10 5 megohms

Tensile Strength: 30 lbs/in (52 N/cm)

Adhesion to Steel :50 oz/in (5.5 N/cm)

Elongation : 30%

Electrolytic Corrosion :1.0 Direct/ A, 1*

Flammability :BU 2*
Storage Stability : Excellent

Solvent Resistance: Excellent

Moisture Resistance : Excellent

UL File # : E20780
CSA File #: LR94980

VDE 0340

IPG#51595胶带
